DigitalSpot 7000 DT

Electrical Specifications

• Auto-switching power supply
• Input voltage range: 100 - 120V/200 - 240V AC, 50/60Hz
• Power consumption: 800VA



Projector Specification

• Model: PLC-XP100L
• Light output: 6.500 ANSI lumens
• Lamp: 330 W NSHA
• Rated lamp life: 3.000 h (eco mode); 2.000 h (normal mode)
• Throw distance ratio: 1.8-2.4 : 1
• Contrast ratio: 2000:1
• LCD panel system: 1.3“ TFT Active Matrix type, 3 panels
• Panel resolution: 1.024 x 768 dots
• Number of pixels: 2.359.296 (1.024 x 763 x 3 panels)



Hardware

• Motherboard: MSI G33 M-F
• Processor: Intel Core2 Duo E6750, 2.66 GHz, 1333 MHz FSB
• Memory:1GB RAM
• Graphics card: nVidia 9800 GT
• Video capture card: AverMedia DVD EZMaker
• Hard disk: Western Digital 500GB Caviar SE16 3.5“
• Gigabit Ethernet



Operation System

• Linux OS



Graphic Engine

• 4 digital gobo layers for image and video control
• Graphic engine supports a combined total of more than 60.000 original and user-created videos/gobos usable on all gobo layers
• Individual X and Y positioning and scaling for each gobo layer
• Layer Media Control Modes (Copy, Add, Subtract, Multi, Minimum and Maximum)
• Banner Effects creating action scripts for Images or Videos
• Digital Iris effect + 160 Masking effects
• Full Key-Stone correction
• Digital strobe effect
• CMY Image and Video Colour Mixing and CTC (Colour Temperature Correction)
• 2 Effect Engines per Layer with more than one hundred effects
• Huge amount of Default Images/Videos
• Import of User Images or Videos
• Supported Image Formats: JPG, TGA, PNG, GIF, PCX, PNM, XPM and LBM (max. 4096 x 4096 pixel)
• Supported Video Formats: MPEG1, MPEG2
• Effect video synchronization
• Preview of projecting output through web interface
• Picture Merging effect in the field up to 64 segments in several different matrice comfiguration
• Projection onto cylindrical/spherical surfaces and angular screens
• Video processing on all gobo layers from a remote streaming video server



Electromechanical Effects

• Zoom
• Focus
• Mechanical iris



Control

• 5″ TFT LCD display & Robe navigation system
• Web access for total control of fixture (user library management)
• Media Content Synchronization in web interface
• 169 control channels max.



Pan/Tilt

• Pan movement range: 530°
• Tilt movement range: 280°
• 16 bit movement resolution
• Controllable speed of Pan/Tilt movement
• Automatic Pan/Tilt position correction
• Built-in Pan/Tilt macro effects



Integrated LEDWash Module

• Light source: 2 x 48 Luxeon Rebel LEDs (RGBW)
• Optical system: 25° beam angle
• RGB colour mixing
• Shutter and adjustable strobe sequences
• Full range dimming



Video inputs:

• Data projector: 1 x S-Video (Mini Din 4 pin), 1 x VGA (Mini D-sub 15 pin)
• Graphic Engine - Standard: 1 x S-Video (Mini Din 4 pin), 1 x Composite video (RCA)
• Graphic Engine - Optional:1 x DVI-D, 1 x VGA (Mini D-sub 15 pin), 1 x SDI/ASI (BNC)
• DMX data in/out: Locking 3-pin and 5-pin XLRs
• ArtNet: RJ 45 (Neutrik Ethercon)
• AC power input: 1.3 m power cord without plug
• 2 x USB 2.0 (series A)



Rigging

• Mounting points: 4 pairs of ¼-turn locks
• 2 x Omega bracket with ¼-turn quick locks
• Safety chain/cord attachment point



Mechanical Specifications

• Height: 882 mm (34.7″)
• Width: 542 mm (21.3″)
• Depth: 629 mm (24.8″)
• Weight: 48 kg (105.8 lbs)
